Arc Flash Hazard Planning and Analysis The United States and Canada Clark Dietz has extensive experience with arc flash planning and analysis throughout the United States and Canada. We assisted the State of Wisconsin, Department of Facilities Development, in creating a master plan and implementation approach for their 7,000 buildings and helped to develop [...]

Inovateus, DeMille Road Solar Facility Clark Dietz provided project management, site civil, structural and electrical engineering services for this three-site project that is one of the largest utility-owned PV solar arrays east of the Mississippi River. The project will generate 45 MW of solar power with 200,000 solar panels, enough to power 9,000 homes. [...]

Gregory Hall HVAC Replacement Urbana-Champaign, IL Constructed in 1939, Gregory Hall was heated and cooled by a combination of five central constant volume forced air heating/cooling systems and radiators. The same five original air systems and steam radiators were still in service in 2008, after numerous repairs and upgrades to the air systems over [...]

Outdoor Municipal Pool Merrill, WI The Merrill Municipal outdoor pool is a public swimming facility that has a large pool with various areas of activities for all ages including slides, lap pools and play area. The bathhouse facility includes a ticketing area, cash room, first aid room, lockers and shower spaces, and quick service [...]

ISU Student Fitness & Kinesiology/Rec. Building Normal, IL This building integrates education and health/wellness, serving as the home for both the School of Kinesiology and Recreation Services. Instructional, clinical and activity space are intermixed throughout the 176,000 GSF building. The Recreation Center also incorporates support spaces for Wellness, Nutrition and Nursing programs that use [...]

Water Treatment Plant Standby Power Upgrade Oak Creek, WI The Oak Creek Water and Sewer Utility Water Treatment Plant and Low Lift Pump Station were constructed in the early 1970s. Since that time, the demands to supply quality water to customers in the Oak Creek community have significantly increased. The original generators used to [...]

UW-Stout Electrical Substation Replacement Stout, WI Challenge With over 9,300 students and enrollment steadily increasing at UW-Stout, changes had to be made to their campus substation. The University was aware that their current substation could not produce enough reliable power for their new enrollment numbers. Built in 1974, maintenance and repairs were becoming more [...]

Armed Forces Reserve Center Madison, WI This new Armed Forces Reserve Center houses units from the Wisconsin National Guard, Army, Navy, and Marine Reserves as part of ongoing Base Realignment and Closure activities nationwide. The bulk of the programmed space is a single 151,233 GSF facility with a 29,000 GSF combined Organizational Maintenance Shop. [...]

Low Lift Pumping Station Improvements Oak Creek, WI The Oak Creek Water and Sewer Utility was experiencing unreliability and component failure of the electrical system at its Low Lift Pumping Station. Clark Dietz evaluated the existing electrical equipment to determine needed replacements, including transformers, switchgear, motor control centers, and instrumentation and controls. Based on [...]

Copper Lake School Security Upgrade Irma, WI At Copper Lake School for Girls, safety of campus inmates, visitors, and Department of Correction’s (DOC) staff are of the highest priority. Strengthening security at the Health Services Unit (HSU) and Access Control Building (ACB) were identified as areas needing improvement. Prior to designing, Clark Dietz worked [...]
